Cambium Networks cnPilot e510 - with PoE injector (RoW)
We are sorry, this product is no longer in our offer.
PCU5E-1YW-MS
0.62 EUR excl. VAT
0.75 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.73 EUR excl. VAT
4.51 EUR incl. VAT
In Stock
Parameters
Download
Video
GPSR
Technical parameters
Wireless features
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11ac, 802.11ac - wave2, 802.11n, 802.11a, 802.11b/g
MU-MIMO:
Yes
Hotspot 2.0:
Yes
Transmission speed - 5GHz [Mb/s]:
866
Transmission speed - 2.4GHz [Mb/s]:
400
Tx power 2.4GHz [dBm]:
24
Tx power 5GHz [dBm]:
25
2.4GHz MIMO:
2 x 2
5GHz MIMO:
2 x 2
Type of antenna:
Built-in
Roaming:
Yes
Antenna gain [dBi]:
9
Connectors and Interfaces
LAN speed:
(1) 10/100/1000Mbps
Gigabit LAN:
Yes
Power
Power over Ethernet:
802.3af
PoE type:
PoE-In (only)
Max. power consumption [W]:
13
Physical characteristics
Protection class:
IP67
Purpose:
Outdoor
Operating temperature [°C]:
-40 up to 65
Weight [g]:
1100
Width [mm]:
215
Height [mm]:
320
Depth [mm]:
50
Software
Operating mode:
Access Point
IPv6 support:
Yes
Default IP address:
192.168.0.1, Dynamic from DHCP
Default login and password:
admin / admin
Video
Product description
Standards based beam forming Wi-Fi for the Outdoors – Enterprise and Industrial campuses, Public Wi-Fi, Hospitality, Education institutions or just about any demanding outdoor environment requiring cost-effective, controller managed WLAN Access Points.
Outdoor 2×2: 2 MU-MIMO dual band 2.4 GHz and 5 GHz 802.11ac wave2 Access Point with PoE injector, 256 users, 16 SSIDs, 400 Mbps data rate on 2.4 GHz, 867 Mbps data rate on 5 GHz, 1 x Gigabit Ethernet port, integrated 8 dBi omnidirectional antenna, PoE powered, integrated electrical heater for cold start, ruggedized - ESD protection, special LTE resilience filtering, UV rated IP67 enclosure, max operating temperature range -30 °C ~ +65 °C, operating humidity 10 % to 95 %, packaged with wall and pole mount brackets, Kensington lock slot, 3 years warranty.
Package Contents
Cloud-managed Access
All cnPilot APs are managed by cnMaestro from the cloud, an onpremises VM or a private datacenter. cnMaestro provides a single-pane-of-glass dashboard for Wi-Fi, Ethernet, fixed wireless broadband and service provider home routers. cnMaestro Essential cloud management is included at no additional cost. There are no setup fees, licenses or recurring costs. cnMaestro includes detailed network statistics, channel utilization graphs, and integrated remote troubleshooting tools to ensure service is always on.
Download
DatasheetGPSR
