MikroTik RouterBOARD RB711-5Hn (MMCX)
We are sorry, this product is no longer in our offer.
MikroTik RouterBOARD RB711-5Hn (MMCX)
×
0/0
Sale
MMCX-NM90
4.97 EUR excl. VAT
6.01 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.61 EUR excl. VAT
0.74 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.69 EUR excl. VAT
4.46 EUR incl. VAT
In Stock
Parameters
Download
GPSR
Technical parameters
Wireless features
Tx power [dBm]:
22
Wireless frequency:
5 GHz
WiFi standards:
802.11n, 802.11a
Transmission speed - 5GHz [Mb/s]:
150
5GHz MIMO:
1 x 1 SISO
Connectors and Interfaces
RF connectors:
(1) MMCX
LAN speed:
(1) 10/100Mbps
Power
Power over Ethernet:
10 .. 28V DC
Power type:
PoE
PoE type:
PoE-In (only)
Max. power consumption [W]:
4,5
Physical characteristics
Design:
RouterBOARD
Operating temperature [°C]:
-30 up to 60
Width [mm]:
105
Depth [mm]:
105
Hardware
CPU:
AR7241
CPU frequency [MHz]:
400
CPU cores:
1
Internal storage [MB]:
64
RAM [MB]:
32
Software
Operating system:
RouterOS - L3
Default IP address:
192.168.88.1
Default login and password:
admin / -
Product description
The RB711-5Hn is a small CPE type RouterBOARD wireless router with an integrated 5GHz 802.11a/n wireless card. RB711 includes RouterOS - the operating system, which can be a router, firewall, bandwidth manager, a CPE and more - all at the same time. RB711-5Hn is equiped with MMCX connector. The integrated wireless card is capable of up to 23dBm transmit power output. Supported frequency: 4800 - 6075Mhz.
Download
Firmware (RouterOS / SwOS) RouterOS software manualGPSR
