Teltonika PR40119K M12 X, 4-Pin, Male Connector

Product description

Mechanical/Environmental

• Voltage rating: 48 V AC / 60 V DC
• Current carrying capacity: 0.5 A
• Conductor cross section, solid wire: AWG 26/1 - AWG 22/1
• Conductor cross section, stranded wire: AWG 26/7 - AWG 22/7
• Temperature range: -40 °C to +85 °C
• Mounting method: Screwable (M12)
• Insertion and withdrawal force: less 30 N
• Life - number of mating cycles: ? 100
• IP rating: IP67 (when plugged in)
• Housing material: GD-Zn (zinc die-cast)
• Contact material: CuZnPb (brass)
• Contact finish material: Ni + Au (nickel-gold)
• Shield material: CuSn (tin bronze)
• Shield finish material: Sn (tin)
• Stuffer cap material: PA
• Finish material: Ni (nickel)
• Weight: 47 g
• RoHS: Yes
• REACH: Yes
