Ubiquiti AMG-Pro, AirGateway Pro
We are sorry, this product is no longer in our offer.
Ubiquiti AMG-Pro, AirGateway Pro
×
0/0
Sale
POE-24-12W
5.59 EUR excl. VAT
6.85 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.62 EUR excl. VAT
0.75 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.70 EUR excl. VAT
4.48 EUR incl. VAT
In Stock
Parameters
Download
GPSR
Technical parameters
Wireless features
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11b/g, 802.11n, 802.11a
Transmission speed - 5GHz [Mb/s]:
150
Transmission speed - 2.4GHz [Mb/s]:
150
Tx power 2.4GHz [dBm]:
23
Tx power 5GHz [dBm]:
21
Security:
WPA2 AES
2.4GHz MIMO:
1 x 1 SISO
5GHz MIMO:
1 x 1 SISO
Type of antenna:
Built-in
Internal antennas:
1
Antenna gain [dBi]:
2
Connectors and Interfaces
WAN speed:
(1) 10/100Mbps
LAN speed:
(1) 10/100Mbps
Power
Power over Ethernet:
24V DC
PoE type:
PoE-Out + PoE-In
Max. power consumption [W]:
6
Physical characteristics
Purpose:
Indoor
Buttons:
Reset, external reset
Operating temperature [°C]:
-30 up to 70
Weight [g]:
70
Width [mm]:
44
Height [mm]:
30
Depth [mm]:
79
Hardware
CPU:
MIPS 74Kc
CPU frequency [MHz]:
560
RAM [MB]:
32
Software
Operating mode:
Client, AP Router, Access Point, Client Router (wisp)
IPv6 support:
Transparent (bridge mode)
Default IP address:
192.168.1.1
Default login and password:
ubnt / ubnt
Product description
The airGateway™ is an affordable product with a compact form factor. It simultaneously connects indoor client devices and powers the outdoor CPE (Customer Premises Equipment). The airGateway is compatible with Ubiquiti PoE Adapters featuring 24V, 0.5A or 15V, 0.8A.
Great equipment
AirGateway-PRO is dual band 2.4 or 5GHz (802.11a/b/g/n) model. The airGateway can operate in any of these network modes to meet the needs of your network: SOHO router, Router and Bridge. The airGateway supports these wireless modes to fulfill your wireless requirements: AP and Station. Such versatile functionality makes the airGateway extremely convenient and economical to deploy.
Package contains
Download
Datasheets Latest Firmware Quick Start GuideGPSR
