UNV NVR NVR304-32S, 32 channels, 4x HDD, easy
We are sorry, this product is no longer in our offer.
UNV NVR NVR304-32S, 32 channels, 4x HDD, easy
×
0/0
2150A00A
Price after login
stiqtyfree:0
_17:
avail:0
infocode: avail
queu:
shipmin:
Not in stock
PCU5E-1YW-MS
0.63 EUR excl. VAT
0.76 EUR incl. VAT
stiqtyfree:0
_17:
avail:0
infocode: avail
queu:
shipmin: 30.1.2026
Expected 30.1.2026
PCU5E-5-MSC
3.78 EUR excl. VAT
4.57 EUR incl. VAT
stiqtyfree:130
_17:
avail:2
infocode: stock
queu:
shipmin:
In Stock
Parameters
Download
GPSR
Technical parameters
Max. recording resolution:
8MP
Connectors and Interfaces
USB ports 3.0:
1
Number of Sata connectors:
4
VGA connector:
Yes
HDMI interface (resolution) [pixels]:
3840 x 2160
Audio:
Yes
LAN speed:
(2) 10/100/1000Mbps
USB ports 2.0:
2
HDMI interface:
Yes
Power
Max. power consumption [W]:
15
Power via connector/terminal:
12V DC
Physical characteristics
Design:
Rackmount
"U" positions:
1
Operating temperature [°C]:
-10 up to 55
Weight [g]:
3150
Width [mm]:
440
Height [mm]:
50
Depth [mm]:
344
Hardware
Number of supported IP cameras:
32
Number of supported HDD:
4
Supported HDD capacity [TB]:
10
Incoming bandwidth [Mb/s]:
160
Outgoing bandwidth [Mb/s]:
64
Compression standard
Video compression:
H.264, H.265
General
Camera class:
Easy
Product description
Medium NVR device NVR304-32S for 32 IP cameras and 4 HDD up to 10 TB. Recorder is equipped with two ports 10 / 100 / 1000 Mbps for network connection and three USB ports for connecting peripherals.
Max consumption of the device is less than 15 W (without connected HDD).
The device is powered by 12V DC adapter which is included
Maximum input rate is 160 Mbps, output rate is 64 Mbps. It supports Ultra 265 / H.265 / H.264 codecs and also allows you to connect third-party cameras that support standard ONVIF.
Package contains
Download
Datasheet Firmware, software a manualyGPSR
